| Multi screw conveyor |
Product name：Multi screw conveyor
Product Description:Multi axis screw conveyor generally refers to the combination of multiple shafts, so as to increase the conveying capacity. Common two screw conveyor is also called double screw conveyor, three screw conveyor, four screw conveyor and six screw conveyor. According to the requirements of working conditions, each shaft can be driven independently or through gears. It can realize the functions of conveying, mixing, mixing and cooling at the same time.
Customization Description: the equipment can be customized according to customer requirements.
Example Model：
| name |
Spiral diameter |
Conveying capacity |
Conveying distance |
Motor power |
| Double screw conveyor |
350mm |
4.5ton/hour |
8100mm |
15kw |
| Triple screw conveyor |
250mm |
30ton/hour |
3500mm |
5.5kw |
| Four screw conveyor |
340mm |
24ton/hour |
2800mm |
11kw |
| Six screw conveyor |
250mm |
30 ton/hour |
1800mm |
7.5kw |
 |
 |
| Two screw mixing conveyor |
Six screw silo |
 |
 |
| Triple screw mixer |
Four screw conveyor |
|
